857725 Murr Elektronik AC/DC Power Supplies
Part#:857725
Manufacturer:Murr Elektronik
Category:AC/DC Power Supplies
Product Lifecycle:Active
Product description
857725 Murrelektronik - MCS POWER SUPPLY 2-PHASE, IN: 340-460VAC OUT: 24-28V/5ADC
Product Details
- Weight 800 g
- Series Transformators/Power Supplies
- Frequency 50...60 Hz
- Inrush current after 1 ms max. 22 A
- Product article number of manufacturer 857725
- Parallel usage/serial usage max. 5 units/max. 2 units
- Input current 0.85 A (400 V AC)
- Primary fusing external max. 10 A
- Input voltage 340...470 V AC
- Unit protection short-circuit and overload protected
- Ripple max. 20 mV eff/rms
- Mains failure bridging time min. 10 ms (400 V AC)
- Spikes max. 100 mV ss/pp
- Output current 5 A (+60 °C); 6 A (+40 °C)
- Dimensions H×W×D 127×68×140 mm
- Relative humidity 5...95%, no condensation
- Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
- Efficiency 88% (400 V AC)
- LED display LED (green) for output voltage
- Temperature range 0...+60 °C (storage temperature -25...+85 °C)
- Mounting method DIN-rail mountable TH35 (EN 60715)
- Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
- Standards IEC 61010-2-201, EN 61204-3, EN 55022 B
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 857725 on Applied Automation is $472.45. Order now.
857725 Related Documents
Manufacturer warranty
857725 Murr Elektronik
$472.45
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$472.45
$472.45 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 857725 with other AC/DC Power Supplies products
Weight
Series
Frequency
Inrush current after 1 ms
Product article number of...
Parallel usage/serial usa...
Input current
Primary fusing external
Input voltage
Unit protection
Selected product
857725
Murr Elektronik
857725 Murrelektronik - MCS POWER SUPPLY 2-PHASE, IN: 340-460VAC OUT: 24-28V/5ADC
Weight800 g
SeriesTransformators/Power Supplie...
Frequency50...60 Hz
Inrush current after 1 msmax. 22 A
Product article number of manufacturer857725
Parallel usage/serial usagemax. 5 units/max. 2 units
Input current0.85 A (400 V AC)
Primary fusing externalmax. 10 A
Input voltage340...470 V AC
Unit protectionshort-circuit and overload p...
SVL2-24-100
SolaHD
SVL2-24-100 SolaHD single phase power supply, 100-240 VAC input, 24 VDC output, 2.1 A, 50W
Weight-
Series-
Frequency-
Inrush current after 1 ms-
Product article number of manufacturer-
Parallel usage/serial usage-
Input current-
Primary fusing external-
Input voltage-
Unit protection-
SVL5-24-100
SolaHD
SVL5-24-100 SolaHD single phase power supply, 100-240 VAC input, 24 VDC output, 5 A, 120W
Weight-
Series-
Frequency-
Inrush current after 1 ms-
Product article number of manufacturer-
Parallel usage/serial usage-
Input current-
Primary fusing external-
Input voltage-
Unit protection-
About the manufacturer
Applied Automation is an authorized Murr Elektronik distributor, offering a robust selection of high-quality components engineered to drive efficiency and innovation in industrial applications. Murr Elektronik, a leader in the electronics industry, specializes in providing sophisticated automation solutions that cater to diverse sectors by integrating cutting-edge technology with unmatched enginee...
About the Product Category
AC/DC power supplies are power supplies that convert alternating current from the grid into direct current that is needed to power most electronics. AC/DC power supplies are integral components in systems that make the world go round.
