7000-18021-2161000 Murr Elektronik Cable Assemblies

Product Details

• Weight
  588 g
• Series
  Connector Systems
• Cable length
  10 m
• Bend radius (moving)
  10× outer Ø
• Product article number of manufacturer
  7000-18021-2161000
• Temperature range (mobile)
  -5...+70 °C
• Temperature range (fixed)
  -30...+70 °C
• Bend radius (fixed)
  5× outer Ø
• Test voltage
  3000 V AC
• Current load capacity
  to DIN VDE 0298-4
• Nominal voltage
  300/500 V AC
• chemical resistance
  good resistance to oil, gasoline and chemicals
• Outer-Ø (jacket)
  5.9 mm ±5%
• Shield
  no
• Material (jacket)
  PVC
• Material property (jacket)
  CFC-, cadmium-, silicone- and lead-free
• Shore hardness (jacket)
  80 ±5 A
• Color (jacket)
  gray
• Wire-Ø incl. isolation
  1.8 mm ±5%
• Material property (wire isolation)
  CFC-, cadmium-, silicone- and lead-free
Color/numbering of wires
bk numbered, gnye longitudinally striped
Shore hardness (wire isolation)
43 ±5 D
Stranding combination
3 wires twisted
Resistor (core)
max. 26 Ω/km (20 °C)
AWG
similar to AWG 18
Diameter (core)
3× 0.75 mm²
Material (wire isolation)
PVC
Approval (cable)
CE conform
Material (wire)
Cu wire, bare
Cable Type
1 (PVC)
Single wire Ø (core)
0.2 mm
Cable weight [g/m]
63,8 g
Construction (core)
24× 0.2 mm (multi-strand wire class 5)
Pollution Degree
3
Housing
Black plastic (gray on request)
Material (gasket)
PUR
Cable identification
216
Temperature range
-25...+85 °C, depending on cable quality
Additional suppressor
Diode/Z-Diode
Switch off delay time
max. 20 ms
Locking material
Steel (galvanized)
Protection
IP67 inserted and tightened (EN 60529)
Material
PBT
Rated surge voltage
0.8 kV
Current consumption
max. 15 mA
Operating voltage
24 V AC ±20% / DC ±25%
Material group
IEC 60664-1, category I
Operating current per contact
max. 4 A
Locking of ports
M3 (recommended torque 0.4 Nm)
Switch off peak
max. 55 V
Form
18021
LED display
yellow
