139.000.55 Werma Buzzers

Product Details

• Conforms with VdS
  No
• Conforms with RoHS CN
  No
• Conforms with GL
  No
• ICAO Certification
  No
• Conforms with AS-I
  No
• Conforms with FCC
  No
• EAC certificate available
  Yes
• Conforms with IC
  No
• Conforms with UL
  No
• Conforms with CCC
  No
• Conform with ATEX-directive
  No
• Acoustic service life
  5,000 h minimum
• Conforms with CE
  Yes
• WEEE
  No
• Number of tones
  32 tone
• Acoustic signal image
  Multi-tone
• Volume (max) at 1m distance
  105,0 dB (A)
• Service life optical
  5,000 h minimum
• Protection class
  Protection class 2
• Pollution degree
  3
Rated operational current
15 mA
Operating voltage tolerance
+/- 0%
Rated operational voltage
24 VDC
Operating voltage type
DC
Operating voltage
9-60V
Working temperature minimum
-25°C
Product weight
350 g
Working temperature maximum
+70°C
Weight with packaging
410 g
Cable entry
Screwed cable gland
Type of fixing
Wall mounting
Tension relief
Present (conforms to VDE)
Connection
Screw terminals
Protection category
IP66
Height
108 mm
cross-sectional area maximum
2,50mm² / 14AWG
Width
136 mm
Length
119 mm
Housing colour
Red
Materials
ABS
