SLG440COM-ER-0800-03 Schmersal Safety Light Curtains

Product Details

• Versions
  p-type
• Voltage type
  DC (direct current)
• Output current, (fail-safe output), maximum
  0.25 A
• Electrical power consumption of the receiver, maximum
  10 W
• Electrical power consumption of the transmitter, maximum
  5 W
• Protection rating
  III
• Switching voltage OSSD, HIGH signal
  24 V
• Storage and transport temperature, maximum
  +70 °C
• Ambient temperature, maximum
  +50 °C
• Ambient temperature, minimum
  -10 °C
• Storage and transport temperature, minimum
  -25 °C
• Degree of protection
  IP67 to EN 60529
• Integral System Diagnostics, status
  Yes
• Height of sensor
  871 mm
• Width of sensor
  27.8 mm
• Length of sensor
  33 mm
• Terminal, Connector, Transmitter
  Connector plug M12, 4-pole
• Terminal connector, Recipient
  Connector plug M12, 5-pole
• Reaction time, maximum
  10 ms
• Gross weight
  1,420 g
Integral System Diagnostics
Yes
Length of cable
100 m
Number of beams
3
Number of fail-safe digital outputs
2
Terminal Connector
Connector
Wave length of the sensor
880 nm
Range, protection field, maximum
12,000 mm
Range, protection field, minimum
300 mm
Standards
EN 61496-1, EN 61496-2, CLC/TS 61496-2
Height of the protection field
800 mm
Enclosure material
Aluminium
Restart interlock (manual reset)
Yes
Detection ability for test bodies at v = 1.6 m/s
800 mm
