SLG 420-E/R0800-03-RF Schmersal Electronic Components

Product Details

• Length of cable, maximum
  100 m
• Versions
  p-type
• Electrical power consumption of the transmitter
  4 W
• Electrical power consumption of the receiver
  8 W
• Output current, (fail-safe output), maximum
  0.5 A
• Switching voltage OSSD, HIGH signal
  24 V
• Voltage type
  DC (direct current)
• Protection rating
  III
• Ambient temperature, minimum
  -25 °C
• Storage and transport temperature, minimum
  -25 °C
• Storage and transport temperature, maximum
  +70 °C
• Degree of protection
  IP67 to EN 60529
• Diameter of sensor
  49 mm
• Ambient temperature, maximum
  +50 °C
• Height of Receiver
  935 mm
• Terminal connector, Recipient
  Connector plug M12, 8-pole
• Length of cable
  100 m
• Height of transmitter
  920 mm
• Terminal Connector
  Connector
• Terminal, Connector, Transmitter
  Connector plug M12, 4-pole
Wave length of the sensor
880 nm
Range, protection field, minimum
300 mm
Range, protection field, maximum
18,000 mm
Restart interlock (manual reset)
Yes
Detection ability for test bodies at v = 1.6 m/s
800 mm
Number of fail-safe digital outputs
2
Height of the protection field
800 mm
Integral System Diagnostics, status
Yes
Integral System Diagnostics
Yes
Reaction time, maximum
10 ms
Number of beams
3
Gross weight
3,780 g
Beam coding available
Yes
Standards
IEC/EN 61496-1/-2
Enclosure material
Aluminium
