SLG 420-E/R0500-02-RF Schmersal Electronic Components

Product Details

• Electrical power consumption of the transmitter
  4 W
• Versions
  p-type
• Output current, (fail-safe output), maximum
  0.5 A
• Length of cable, maximum
  100 m
• Electrical power consumption of the receiver
  8 W
• Switching voltage OSSD, HIGH signal
  24 V
• Ambient temperature, maximum
  +50 °C
• Storage and transport temperature, maximum
  +70 °C
• Storage and transport temperature, minimum
  -25 °C
• Voltage type
  DC (direct current)
• Degree of protection
  IP67 to EN 60529
• Protection rating
  III
• Ambient temperature, minimum
  -25 °C
• Height of Receiver
  635 mm
• Diameter of sensor
  49 mm
• Height of transmitter
  620 mm
• Terminal, Connector, Transmitter
  Connector plug M12, 4-pole
• Terminal connector, Recipient
  Connector plug M12, 8-pole
• Range, protection field, maximum
  18,000 mm
• Wave length of the sensor
  880 nm
Terminal Connector
Connector
Range, protection field, minimum
300 mm
Length of cable
100 m
Height of the protection field
500 mm
Detection ability for test bodies at v = 1.6 m/s
500 mm
Number of fail-safe digital outputs
2
Number of beams
2
Standards
IEC/EN 61496-1/-2
Restart interlock (manual reset)
Yes
Reaction time, maximum
10 ms
Integral System Diagnostics, status
Yes
Integral System Diagnostics
Yes
Beam coding available
Yes
Enclosure material
Aluminium
Gross weight
2,780 g
