SLG440-ER-0800-03-H1 Schmersal Safety Light Curtains
Part#:SLG440-ER-0800-03-H1
Manufacturer:Schmersal
Alt. Part#:103009190
Product Lifecycle:Active
Get a quick Quote!
SLG440-ER-0800-03-H1 Schmersal - Safety light curtains, Safety light grids; Safety light grids; Safety type 4 in accordance with IEC 61496-1; User-friendly parameter setting, no tools required; Reliable safety concept in case of interferences (EMC, welding sparks); Process safety with hi
About the manufacturer: Schmersal is one of the manufacturers that offers Safety Light Curtains that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the SLG440-ER-0800-03-H1 Schmersal price in the box on the right side or send a quick quote.
Product Details
- Output current, (fail-safe output), maximum 0.25 A
- Versions p-type
- Electrical power consumption of the transmitter, maximum 5 W
- Electrical power consumption of the receiver, maximum 10 W
- Switching voltage OSSD, HIGH signal 24 V
- Protection rating III
- Voltage type DC (direct current)
- Storage and transport temperature, maximum +70 °C
- Storage and transport temperature, minimum -25 °C
- Ambient temperature, minimum -25 °C
- Ambient temperature, maximum +50 °C
- Degree of protection IP67 to EN 60529
- Height of Receiver 920 mm
- Width of sensor 27.8 mm
- Length of sensor 33 mm
- Height of transmitter 910 mm
- Terminal, Connector, Transmitter Connector plug M12, 4-pole
- Terminal connector, Recipient Connector plug M12, 8-pole
- Terminal Connector Connector
- Wave length of the sensor 880 nm
- Length of cable 100 m
- Range, protection field, maximum 20,000 mm
- Range, protection field, minimum 3,000 mm
- Detection ability for test bodies at v = 1.6 m/s 400 mm
- Height of the protection field 800 mm
- Number of fail-safe digital outputs 2
- Number of beams 3
- Restart interlock (manual reset) Yes
- Standards EN 61496-1, EN 61496-2, CLC/TS 61496-2
- Bluetooth Yes
- Integral System Diagnostics, status Yes
- Gross weight 1,479.5 g
- Enclosure material Aluminium
- 7-segment display Yes
- Beam coding available Yes
- Integral System Diagnostics Yes
- Reaction time, maximum 10 ms
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
SLG440-ER-0800-03-H1 Description
SLG440-ER-0800-03-H1 Schmersal - Safety light curtains, Safety light grids; Safety light grids; Safety type 4 in accordance with IEC 61496-1; User-friendly parameter setting, no tools required; Reliable safety concept in case of interferences (EMC, welding sparks); Process safety with hi
Related documents SLG440-ER-0800-03-H1 Specs
