85722 Murr Elektronik Power Supply Accessories

Product Details

• Weight
  790 g
• Series
  Transformators/Power Supplies
• Product article number of manufacturer
  85722
• Frequency
  50...60 Hz
• Input fuse (internal)
  6.3 A (T)
• Input voltage
  85...265 V AC/90...250 V DC
• Input current
  1.2 A (100 V AC); 0.6 A (240 V AC)
• Parallel usage/serial usage
  max. 5 units/max. 2 units
• Power factor
  0.87 (230 V AC)
• Inrush current after 1 ms
  max. 3.5 A (230 V AC)
• Spikes
  max. 200 mV ss/pp
• Unit protection
  short-circuit and overload protected
• Ripple
  max. 50 mV eff/rms
• Mains failure bridging time
  min. 30 ms (100 V AC); 2.5 A (48 V DC)
• Output current
  2.5 A
• Power Boost
  Iout N × 150% (min. 4 s)
• LED display
  LED (green): OK; LED (red): overload, overheating or short-circuit
• Protection
  IP20
• Efficiency
  92.8% (110 V AC); 94.6 % (230 V AC)
• Temperature range
  -40...+60 °C, ...+70 °C derating (storage temperature -40...+80 °C)
Connection
Push-In spring clamp terminals
Relative humidity
5...95%, no condensation
Mounting method
4 hole screw mounting
Standards
IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47
Output voltage
48 V DC (SELV), ±1%; 48...56 V adjustable
Dimensions H×W×D
123×50×138 mm
