85642 Murr Elektronik AC/DC Power Supplies
Part#:85642
Manufacturer:Murr Elektronik
Category:AC/DC Power Supplies
Product Lifecycle:Active
Product description
85642 Murrelektronik - EVOLUTION+ POWER SUPPLY 3-PHASE, IN: 360-520VAC OUT: 22-28V/20ADC, Extra-power - for 4 seconds 50% additional power, Alarm Contact and varnished PCB
Product Details
- Weight 2200 g
- Series Transformators/Power Supplies
- Inrush current after 1 ms max. 19 A
- Product article number of manufacturer 85642
- Primary fusing external max. 3× 20 A
- Input current 3× 1.3 A
- Frequency 50...60 Hz
- Input voltage 3× 324...572 V AC/480...745 V DC
- Ripple max. 50 mV eff/rms
- Parallel usage/serial usage max. 5 units/max. 2 units
- Mains failure bridging time min. 19 ms (400 V AC)
- Unit protection short-circuit and overload protected
- Spikes max. 100 mV ss/pp
- Output current 20 A (+55 °C); 15.8 A (+70 °C)
- LED display LED (green): OK; LED (red): overload
- Alarm output electronic relay max. 30 V DC/0.1 A, group alarm
- Standards IEC 61010-2-201, EN 61204-3, EN 55011 A, EN 61000-3-2, SEMI F47
- Protection Varnished board
- Power Boost Iout N × 150% (min. 4 s)
- Output voltage 24 V DC (SELV), ±1%; 22...28 V adjustable
- Efficiency 90% (3× 400 V AC); 89% (3× 520 V AC)
- Relative humidity 5...95%, no condensation
- Temperature range -25...+70 °C (storage temperature -40...+85 °C)
- Mounting method DIN-rail mountable TH35 (EN 60715)
- Dimensions H×W×D 132×113×136 mm
- Connection Screw terminals
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 85642 on Applied Automation is $578.75. Order now.
