85135 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  900 g
• Series
  Transformators/Power Supplies
• Product article number of manufacturer
  85135
• Input fuse (internal)
  5 A (T)
• Inrush current after 1 ms
  max. 18 A (230 V AC)
• Frequency
  50...60 Hz
• Input current
  4.3 A (100 V AC); 2.1 A (240 V AC)
• Input voltage
  90...132 V AC/173...264 V AC
• LED display
  LED (green) for output voltage
• Mains failure bridging time
  min. 12 ms (115 V AC); min. 30 ms (230 V AC)
• Parallel usage/serial usage
  no/yes (max. 2 units)
• Ripple
  max. 10 mV eff/rms
• Unit protection
  short-circuit and overload protected
• Output current
  10 A (+40 °C); 7.5 A (+55 °C)
• Spikes
  max. 50 mV ss/pp
• Connection
  Screw terminals
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Dimensions H×W×D
  125×68×125 mm
• Relative humidity
  20...90%, no condensation
• Efficiency
  86% (115 V AC); 87% (230 V AC)
Standards
IEC 61010-2-201, EN 61204-3, EN 61000-3-2
Protection
IP20
Temperature range
0...+40 °C, ...+55 °C derating (storage temperature -20...+85 °C)
Output voltage
24 V DC ±1%; 23...28 V adjustable
