85071 Murr Elektronik AC/DC Power Supplies
Part#:85071
Alt. Part#:85691
Manufacturer:Murr Elektronik
Category:AC/DC Power Supplies
Product Lifecycle:Active
Product description
85071 Murrelektronik - MCS POWER SUPPLY 3-PHASE, IN: 360-550VAC OUT: 24-28V/10ADC
Product Details
- Weight 1300 g
- Series Transformators/Power Supplies
- Product article number of manufacturer 85071
- Input current 3× 0.65 A
- Frequency 50...60 Hz
- Inrush current after 1 ms max. 15 A
- Input voltage 3× 360...550 V AC
- Parallel usage/serial usage max. 5 units/max. 2 units
- Spikes max. 100 mV ss/pp
- Primary fusing external max. 3× 2 A
- Unit protection short-circuit and overload protected
- Temperature range 0...+60 °C (storage temperature -25...+85 °C)
- Output current 10 A (+60 °C); 12 A (+40 °C)
- Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
- Mains failure bridging time min. 11 ms (500 V AC)
- LED display LED (green) for output voltage
- Ripple max. 20 mV eff/rms
- Dimensions H×W×D 127×68×198 mm
- Efficiency 90%
- Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
- Relative humidity 5...95%, no condensation
- Standards IEC 61010-2-201, EN 61204-3, EN 55022 B
- Mounting method DIN-rail mountable TH35 (EN 60715)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 85071 on Applied Automation is $543.50. Order now.
