59819 Murr Elektronik I/O Systems
Part#:59819
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
59819 Murrelektronik - MVP12-P6 DIO16 8xM12A IOLA12 E0
Product Details
- Weight 240 g
- Series Field Bus System
- Monitoring - no voltage yes
- Short-circuit and overload yes
- Actuator warning yes
- Monitoring - under voltage yes
- Diagnostic via LED per module and channel
- Communication status via LED
- I/O ports M12, 5-pole, A-coded
- Product article number of manufacturer 59819
- Cycle time min. 1 ms
- Operating modes COM3 (230.4 kBaud)
- PIN 2 Input/output/DIO (port X0...X7)
- PIN 4 Input/output/DIO (port X0...X7)
- IO-Link Device
- Port Class A
- Input filter 0…15 ms
- Specification IO-Link V1.1.2, compatible with: IO-Link V1.1.3
- Type Type 1 + type 3
- Operating voltage (US) 24 V DC (18...30 V DC)
- LED display US-IOL: sensor power supply IOL (green: OK)
- Current consumption max. 40 mA
- Mounting method 2-hole screw mounting
- Protection IP68
- Dimensions H×W×D 126×50×34.5 mm
- Switching current per output max. 0.5 A
- Temperature range -25...+70 °C (storage temperature -40...+85 °C)
- Installation height max. max. 3000 m above sea level
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 59819 on Applied Automation is $343.30. Order now.
