57361 Murr Elektronik I/O Systems
Part#:57361
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
57361 Murrelektronik - CUBE20S Analog output module AO4, 4X16Bit (U 0...10 V)
Product Details
- Weight 65 g
- Series Field Bus System
- Current consumption max. 60 mA from system, max. 25 mA externally (UI), idle load
- Monitoring - no voltage no
- Short-circuit and overload yes
- Module supply via system connection
- Actuator warning per module via LED and BUS
- Monitoring - under voltage yes
- Wire break upper/lower limit overload per module via LED and BUS
- Load 5 kΩ
- Input range 0...10 V
- Diagnostic via LED per module and channel
- Product article number of manufacturer 57361
- Diagnostic via BUS per module
- Communication status via LED
- Dimensions H×W×D 109×12.9×76.5 mm
- Conversion time (analog) 200 µs (all channels)
- Connection Spring clamp plug-in terminals: max. 1.5 mm² (AWG 16)
- Galvanic isolation 500 V DC between inputs and internal communication
- Temperature range 0...+60 °C (storage temperature -25...+70 °C)
- Accuracy max. 0.5%
- Resolution (analog) 15 Bit + sign
- Protection IP20
- Mounting method DIN-rail mountable (EN 60715)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 57361 on Applied Automation is $389.05. Order now.
