57340 Murr Elektronik I/O Systems
Part#:57340
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
57340 Murrelektronik - CUBE20S DIGITAL OUTPUT MODULE DO4, 4x24VDC 0,5A
Product Details
- Weight 65 g
- Series Field Bus System
- Diagnostic via BUS per module
- Short-circuit and overload yes
- Monitoring - no voltage no
- Diagnostic via LED per module and channel
- Module supply via system connection
- Communication status via LED
- Monitoring - under voltage yes
- Current consumption max. 55 mA
- Product article number of manufacturer 57340
- Switching current per output max. 0.5 A (short-circuit and overload protected)
- Actuator supply UA 24 V DC (EN 61131-2), max. 2 A
- Output delay time 175 ns
- Galvanic isolation 500 V DC between outputs and internal communication
- Lamp load 5 W
- Protection IP20
- Dimensions H×W×D 109×12.9×76.5 mm
- Temperature range 0...+60 °C (storage temperature -25...+70 °C)
- Connection Spring clamp plug-in terminals: max. 1.5 mm² (AWG 16)
- Mounting method DIN-rail mountable (EN 60715)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 57340 on Applied Automation is $93.75. Order now.
57340 Related Documents
Manufacturer warranty
57340 Murr Elektronik
$93.75
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$93.75
$93.75 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 57340 with other I/O Systems products
Weight
Series
Diagnostic via BUS
Short-circuit and overloa...
Monitoring - no voltage
Diagnostic via LED
Module supply
Communication status
Monitoring - under voltag...
Current consumption
Selected product
57340
Murr Elektronik
57340 Murrelektronik - CUBE20S DIGITAL OUTPUT MODULE DO4, 4x24VDC 0,5A
Weight65 g
SeriesField Bus System
Diagnostic via BUSper module
Short-circuit and overloadyes
Monitoring - no voltageno
Diagnostic via LEDper module and channel
Module supplyvia system connection
Communication statusvia LED
Monitoring - under voltageyes
Current consumptionmax. 55 mA
Weight-
Series-
Diagnostic via BUS-
Short-circuit and overload-
Monitoring - no voltage-
Diagnostic via LED-
Module supply-
Communication status-
Monitoring - under voltage-
Current consumption-
About the manufacturer
Applied Automation is an authorized Murr Elektronik distributor, offering a robust selection of high-quality components engineered to drive efficiency and innovation in industrial applications. Murr Elektronik, a leader in the electronics industry, specializes in providing sophisticated automation solutions that cater to diverse sectors by integrating cutting-edge technology with unmatched enginee...
Recently viewed products
Relevant products
FAQ
What is the price of 57340?
Purchase the 57340 from Applied Automation at the price of $93.75. Order today.
Out if stock but available for backorder.
57340 Murrelektronik - CUBE20S DIGITAL OUTPUT MODULE DO4, 4x24VDC 0,5A
