57230 Murr Elektronik I/O Systems
Part#:57230
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
57230 Murrelektronik - CUBE20S ANALOG INPUT MODULE AI2, 2X16Bit TH 22 Parameter Bytes
Product Details
- Weight 65 g
- Series Field Bus System
- Short-circuit and overload yes
- Wire break upper/lower limit overload per channel via LED and BUS
- Monitoring - no voltage no
- Diagnostic via LED per module and channel
- Monitoring - under voltage yes
- Product article number of manufacturer 57230
- Communication status via LED
- Diagnostic via BUS per module
- Current consumption max. 75 mA from the system, max. 30 mA externally (UI)
- Module supply via system connection
- Resolution (analog) 15 Bit + sign
- Dimensions H×W×D 109×12.9×76.5 mm
- Accuracy max. ±0.3%, cold junction compensation
- Temperature range 0...+55 °C (storage temperature -20...+85 °C)
- Conversion time (analog) max. 4.2...324.1 ms, 50 Hz (per channel)
- Connection Spring clamp plug-in terminals: max. 1.5 mm² (AWG 16)
- Type B, C, E, J, K, L, N, R, S, T
- Protection IP20
- Mounting method DIN-rail mountable (EN 60715)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 57230 on Applied Automation is $359.15. Order now.
57230 Related Documents
Manufacturer warranty
57230 Murr Elektronik
$359.15
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$359.15
$359.15 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 57230 with other I/O Systems products
Weight
Series
Short-circuit and overloa...
Wire break upper/lower li...
Monitoring - no voltage
Diagnostic via LED
Monitoring - under voltag...
Product article number of...
Communication status
Diagnostic via BUS
Selected product
57230
Murr Elektronik
57230 Murrelektronik - CUBE20S ANALOG INPUT MODULE AI2, 2X16Bit TH 22 Parameter Bytes
Weight65 g
SeriesField Bus System
Short-circuit and overloadyes
Wire break upper/lower limit overloadper channel via LED and BUS
Monitoring - no voltageno
Diagnostic via LEDper module and channel
Monitoring - under voltageyes
Product article number of manufacturer57230
Communication statusvia LED
Diagnostic via BUSper module
Weight-
Series-
Short-circuit and overload-
Wire break upper/lower limit overload-
Monitoring - no voltage-
Diagnostic via LED-
Monitoring - under voltage-
Product article number of manufacturer-
Communication status-
Diagnostic via BUS-
About the manufacturer
Applied Automation is an authorized Murr Elektronik distributor, offering a robust selection of high-quality components engineered to drive efficiency and innovation in industrial applications. Murr Elektronik, a leader in the electronics industry, specializes in providing sophisticated automation solutions that cater to diverse sectors by integrating cutting-edge technology with unmatched enginee...
Recently viewed products
Relevant products
FAQ
What is the price of 57230?
Purchase the 57230 from Applied Automation at the price of $359.15. Order today.
Out if stock but available for backorder.
57230 Murrelektronik - CUBE20S ANALOG INPUT MODULE AI2, 2X16Bit TH 22 Parameter Bytes
