56761 Murr Elektronik I/O Systems

Product Details

• Weight
  177 g
• Series
  Field Bus System
• Lamp load
  10 W
• Temperature range
  0...+55 °C (storage temperature -20...+75 °C)
• Compatible with:
  56521; 56526
• RS485-Type
  galvanically separated, M12 female 5-pole, B-coded
• Protection
  IP67
• Short-circuit and overload
  yes
• Mounting method
  2-hole screw mounting
• RS232-Type
  galvanically separated, M12 female 5-pole, B-coded
• Monitoring - under voltage
  yes
• Monitoring - no voltage
  yes
• Actuator warning
  per channel via LED and BUS
• Diagnostic via BUS
  per module and channel
• Dimensions H×W×D
  151×30×34.5 mm
• Diagnostic via LED
  per module and channel
• Fieldbus
  via internal system connection
• Product article number of manufacturer
  56761
• Communication status
  via LED
• I/O ports
  M12 (female) 5-pole, A-coded
Sensor-system/actuator supply
via internal system connection (max. 2× 4 A)
Current consumption
max. 80 mA
PIN 2
Input/Output/Diagnostic
PIN 4
Input/Output
LED display
US: sensor supply and internal supply voltage (green: OK); UA: actuator supply (green: OK)
Input filter
1 ms
Type
for 3-wire sensors or mechanical switches, PNP
Transfer parameters
RS232: 230.4 kbps, full duplex; RS485: 230.4 kbps, half duplex
Sensor supply US
24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Switching current per output
max. 0.5 A (short-circuit and overload protected)
Actuator supply UA
24 V DC (EN 61131-2), via system connection (max. 4 A)
