56006 Murr Elektronik I/O Systems

Product Details

• Weight
  170 g
• Series
  Field Bus System
• Monitoring - no voltage
  no
• Diagnostic via BUS
  per module and channel
• Short-circuit and overload
  yes
• Diagnostic via LED
  per module
• Monitoring - under voltage
  yes
• Communication status
  via LED and BUS
• Product article number of manufacturer
  56006
• Addressing
  DCP
• Internal system connection
  4× spring clamp plug-in terminals, max. 2.5 mm² (max. 12 A)
• I/O ports
  8× spring clamp plug-in terminals, max. 2.5 mm²
• Specification
  V2.2, Conformance Class B
• Fieldbus
  Ethernet 10/100 Mbit/s; 2× RJ45 (female)
• Sensor-system/actuator supply
  4× spring clamp plug-in terminals, max. 2.5 mm² (max. 12 A)
• I/O capacity
  max. 1 024 Byte (Input), max. 1 024 Byte (Output)
• Terminal row X3 (4 channels)
  Input
• Terminal row X2 (4 channels)
  Input
• Machine Option Management
  yes
• Input filter
  1 ms
Module capacity
max. 15
Dimensions H×W×D
117×56×47 mm
Temperature range
0...+55 °C (storage temperature -20...+85 °C)
Current consumption
max. 150 mA
Mounting method
DIN-rail mountable (EN 60715)
Sensor supply US
24 V DC (EN 61131-2), max. 700 mA per module
Galvanic isolation
500 V DC between I/O and system electronics
Protection
IP20
Type
PNP (EN 61131-2)
Operating voltage
24 V DC (EN 61131-2)
