55556 Murr Elektronik I/O Systems
Part#:55556
Manufacturer:Murr Elektronik
Category:I/O Systems
Product Lifecycle:Active
Product description
55556 Murrelektronik - MVK-MPNIO F DI16/8 7/8" IRT, MVK ProfiNet/PROFIsafe Compact module, metal, ProfiNet/PROFIsafe via M12-d, Energy via 7/8'' 5-pol.
Product Details
- Weight 795 g
- Series Field Bus System
- Wire break detection yes
- Actuator warning per channel via LED and BUS
- Monitoring - no voltage yes
- Cross-link detection Sensor/Actuator
- Short-circuit and overload yes
- Diagnostic via BUS per module and channel
- Monitoring - under voltage yes
- Product article number of manufacturer 55556
- Diagnostic via LED per module and channel
- Communication status via LED
- SIL up to 3
- SIL CL up to 3
- PL up to e
- PFH 1.70E-9
- Category up to 4
- Service life 20 years
- DC 98%
- Shared Device yes, for 2 controls
- MRP yes
- Fieldbus Ethernet 10/100 Mbit/s; M12, D-coded
- Protection IP67
- Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
- I/O ports M12, 5-pole, A-coded
- Specification V2.2, Conformance Class C (IRT)
- Addressing DCP
- Dimensions H×W×D 44×63×225 mm
- Mounting method 2-hole screw mounting
- Temperature range -20...+55 °C (storage temperature -40...+70 °C)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 55556 on Applied Automation is $1,730.20. Order now.
