55516 Murr Elektronik I/O Systems

Product Details

• Weight
  1040 g
• Series
  Field Bus System
• Monitoring - no voltage
  yes
• Short-circuit and overload
  yes
• Monitoring - under voltage
  yes
• Cable break
  per port
• Actuator warning
  per channel via LED and BUS
• Diagnostic via LED
  per module and channel
• Communication status
  via LED
• Diagnostic via BUS
  per module and channel
• Product article number of manufacturer
  55516
• Addressing
  DCP
• PROFINET Netload Class
  III
• MRP
  yes
• Shared Device
  yes, for 2 controls
• FSU (Fast-Start-Up)
  max. 500 ms
• I/O ports
  M12, 5-pole, A-coded
• Fieldbus
  Ethernet 10/100 Mbit/s; Push Pull RJ45 Data connector
• PIN 2
  Input (port X3...X5); Output (port X0...X2); U-Actuator IO-Link Class B (port X6, X7)
• Sensor-system/actuator supply
  Push Pull Power connector, max. 12 A
Operating modes
COM1; COM2; COM3 (automatic)
Specification
IO-Link Master V1.1.2
Port Class
Class B (galvanically separated)
PIN 4
Input (port X3...X5); Output (port X0...X2); IO-Link Master (port X6, X7)
Temperature range
0...+55 °C (storage temperature -20...+70 °C)
Transfer parameters
32 Byte (In) 32 Byte (Out) per IO-Link port
Lamp load
10 W
IO-Link
2× Master
Protection
IP67
Mounting method
2-hole screw mounting
Actuator supply UA
24 V DC (EN 61131-2), max. 12 A
Type
for 3-wire sensors or mechanical switches, PNP, IO-Link Devices
Dimensions H×W×D
42.7×63×225 mm
Sensor supply US
24 V DC (EN 61131-2), max. 200 mA (M12 female)/max. 1 A (IO-Link female), short-circuit and overload protected
Switching current per output
max. 2 A (short-circuit and overload protected)
