10510 Murr Elektronik Line Filters & Conditioners

Product Details

• Weight
  450 g
• Series
  Filter Modules
• Product article number of manufacturer
  10510
• Dimensions H×W×D
  107×65×39 mm
• Functional description
  The 3-phase and one-stage EMC filters MEF 3/1 are used in the range 0.1...30 MHz and dampen interferences found in cables from the mains, supply units and control systems. They are suitable for TN-S, TN-C-S, and TT networks. The best results are obtained
• Overload current
  18× (IN t) max. 0.5 ms; 1.5× (IN t) max. 1 min. (1× per hour)
• Connection cross section
  0.2...6 mm² single core (AWG 24...9); 0.2...4 mm² multiple core (AWG 24...11)
• Operating voltage
  max. 4× 440 V AC
• Connection
  Screw connection, touch protected
• Test isolation voltage
  2.7 kV (L - N), 2 s; 2.1 kV (L - L), 2 s (EN 60939-2)
• Operating frequency
  50...60 Hz
• Consumption
  max. 3 mA (250 V AC)
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Climatic category
  25/085/21 (EN 60068-1)
