141.000.55 Werma Buzzers

Product Details

• Conforms with RoHS CN
  No
• Conforms with VdS
  No
• ICAO Certification
  No
• Conforms with AS-I
  No
• Conforms with GL
  No
• EAC certificate available
  Yes
• Conforms with FCC
  No
• Conforms with UL
  No
• Conforms with IC
  No
• Conforms with CCC
  No
• Conform with ATEX-directive
  No
• WEEE
  No
• Conforms with CE
  Yes
• Number of tones
  32 tone
• Acoustic service life
  5,000 h minimum
• Volume (max) at 1m distance
  110,0 dB (A)
• Acoustic signal image
  Multi-tone
• Service life optical
  5,000 h minimum
• Pollution degree
  3
• Rated operational current
  120 mA
Protection class
Protection class 2
Rated operational voltage
24 VDC
Operating voltage type
DC
Product weight
515 g
Operating voltage tolerance
+/- 0%
Operating voltage
9-60V
Type of fixing
Wall mounting
Weight with packaging
598 g
Working temperature maximum
+70°C
Working temperature minimum
-25°C
Tension relief
Present (conforms to VDE)
Cable entry maximum
d = 12 mm
Cable entry minimum
d = 8 mm
Cable entry
Screwed cable gland
cross-sectional area maximum
2,50mm² / 14AWG
Connection
Screw terminals
Protection category
IP66
Width
165 mm
Materials
PC/ABS
Length
132 mm
Height
136 mm
Housing colour
Red
