16166697 WEG AC Motors

Product Details

• Output rating
  500 HP
• Flange
  Without
• Terminal box¹
  Left position
• Altitude
  1000 m.a.s.l.
• Synchronous speed
  1800 rpm
• Number of poles
  4
• Voltage
  4160 V
• Standard
  NEMA MG-1
• Temperature rise
  80 K
• Mounting
  F-1
• Approx. weight³
  4335 lb
• Ambient temperature
  -20°C to +40°C
• Rotation¹
  CW
• Degree of Protection
  IP24
• Noise level²
  78.0 dB(A)
• Duty Cycle
  Cont.(S1)
• No load current
  21.7 A
• Locked rotor time
  43s (cold) 24s (hot)
• Starting Method
  Direct On Line
• Locked rotor torque
  100 %
LRC
6.5x(Code G)
Breakdown torque
220 %
Rated torque
1470 ft.lb
Moment of inertia (J)
136 sq.ft.lb
Service factor
1.00
Insulation Class
F
Rated speed
1783 rpm
L. R. Amperes
407 A
Frequency
60 Hz
Output
500 HP (370 kW)
Number of Poles
4
Rated current
62.6 A
Slip
0.94 %
Rated voltage
4160 V
Frame
5010/11
