04030EP3OFP324TS-W22 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  380 V
• Output Rating
  40 HP
• Rated Speed
  2960 rpm
• Flange Type
  Without
• Flange
  Without
• Terminal box¹
  Left position
• Synchronous speed
  3000 rpm
• Number of poles
  2
• Output rating
  40 HP
• Voltage
  380-400-415 V
• Approx. weight³
  525 lb
• Standard
  NEMA MG-1
• Degree of Protection
  IP55
• Enclosure
  IC411 - TEFC
• Noise level²
  74.0 dB(A)
• Rotation¹
  Both (CW and CCW)
• Mounting
  F-1
• Temperature rise
  80 K
• Duty Cycle
  Cont.(S1)
Starting Method
Direct On Line
Service factor
1.15
Altitude
1000 m.a.s.l.
Insulation Class
F
Breakdown torque
215 %
Design
B
Moment of inertia (J)
4.24 sq.ft.lb
Ambient temperature
-20°C to +40°C
Locked rotor time
45s (cold) 25s (hot)
No load current
13.9 A
Locked rotor torque
200 %
Rated torque
71.0 ft.lb
LRC
5.8x(Code F)
Frequency
50 Hz
Rated current
55.7 A
Output
40 HP (30 kW)
L. R. Amperes
323 A
Rated speed
2960 rpm
Slip
1.33 %
Number of Poles
2
Rated voltage
380 V
Frame
324/6TS
