RSS260-I2-SD-ST Schmersal Safety Switches

Product Details

• Interfering radiation
  IEC 61000-6-4
• EMC rating
  IEC 60947-3
• Voltage drop Ud, maximum
  2 V
• Voltage, Utilisation category DC13
  24 VDC
• Current, Utilisation category DC13
  0.25 A
• Current leakage Ir
  0.5 mA
• Current, Utilisation category DC12
  0.25 A
• Versions
  p-type
• Voltage, Utilisation category DC12
  24 VDC
• Switching frequency, approx.
  1 Hz
• Operating current
  150 mA
• Required rated short-circuit current to EN 60947-5-1
  100 A
• Rated operating voltage, minimum
  20.4 VDC
• Voltage type
  DC (direct current)
• Rated operating voltage, maximum
  26.4 VDC
• Rated operating voltage
  24 VDC -15% / +10%
• Overvoltage category
  III
• Degree of pollution to VDE 0100
  3
• Rated impulse withstand voltage Uimp
  0.8 kV
• No-load supply current I0
  100 mA
Rated insulation voltage Ui
32 VDC
Restistance to shock
30 g / 11 ms
Resistance to vibrations to EN 60068-2-6
10 … 55 Hz, amplitude 1 mm
Storage and transport temperature, maximum
+85 °C
Ambient temperature, maximum
+65 °C
Degree of protection
IP65 to EN 60529, IP67 to EN 60529
Ensured switch distance OFF Sar, lateral
15 mm
Ambient temperature, minimum
-25 °C
Length of sensor
29.5 mm
Storage and transport temperature, minimum
-25 °C
Height of sensor
18 mm
Width of sensor
39.2 mm
Note
The cable section of the interconnecting cable must be observed for both wiring variants! Cable length and cable section alter the voltage drop depending on the output current
Terminal Connector
Connector M8
Switch distance Sn
front 12 mm, lateral 9 mm
Ensured switching distance ON, side
6 mm
Ensured switching distance OFF, front
18 mm
Ensured switching distance ON, front
10 mm
Note (Repeat accuracy R)
Axial offset: The long side allows for a maximum height misalignment (x) of sensor and actuator of 8 mm (e.g. mounting tolerance or due to guard door sagging). The axial misalignment (y) is max. ± 18 mm (see figure: Operating principle). Minimum clearance
Hysteresis (Switch distance), maximum
2 mm
Actuating panels
lateral, front side
Mounting
A 20 mm screw length usually suffices to mount the sensor. When the mounting plates are used, we recommend 25 mm long screws.
Number of semi-conductor outputs with signaling function
1
Repeat accuracy R R
0.5 mm
Number of Series-wiring of sensors
31
Integral System Diagnostics, status
Yes
Number of fail-safe digital outputs
2
Number of LEDs
3
Short-circuit recognition
Yes
Cascadable
Yes
Safety functions
Yes
Diagnostic output
Yes
Duration of risk, maximum
200 ms
Short circuit detection
Yes
Serial diagnostics
Yes
Reaction time, maximum
100 ms
Time to readiness, maximum
2,000 ms
Enclosure material
Plastic, thermoplastic, self-extinguishing
Housing construction form
Block
Coding level according to ISO 14119
High
general information
Individual coding, multiple teaching
Installation conditions (mechanical)
not flush
Gross weight
60 g
Active area
lateral, front
Standards
IEC 60947-5-3
Sensor topology
Sensor for series wiring
Active principle
RFID
