RDLMBL Schmersal Pushbuttons
Part#:RDLMBL
Manufacturer:Schmersal
Alt. Part#:101188172
Product Lifecycle:Active
Get a quick Quote!
RDLMBL Schmersal - Command and signalling devices; "R" program; Illuminated pushbutton with membrane; Symbols still clearly visible under transparent membrane
About the manufacturer: Schmersal is one of the manufacturers that offers Pushbuttons that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the RDLMBL Schmersal price in the box on the right side or send a quick quote.
Product Details
- Restistance to shock 50 g
- Ambient temperature, maximum +75 °C
- Ambient temperature, minimum -25 °C
- Switching frequency 1,200 /h
- Degree of protection IP65
- Thickness of the front panel, maximum 6 mm
- Spacing 40 x 50 mm
- Thickness, of the front panel, minimum 1 mm
- Diameter hole, with tolerance indication 22.3 + 0.4 mm
- Diameter hole 22.3 mm
- Diameter of touch surface 28 mm
- Diameter of the front ring 39.5 mm
- Height of touch surface 1.5 mm
- Height 12 mm
- Diameter total 39.5 mm
- Tightening torque of the screw 0.6 Nm
- Actuating force, approx. 1.5 N
- Mechanical life, minimum 1,000,000 Operations
- Mounting Mounting flange ELM
- Actuating stroke 4 mm
- Unlocking without
- Integral System Diagnostics, general No
- Fully insulated Yes
- Gross weight 45 g
- Mounting flange Yes
- Membrane Yes
- Standards EN 60947-5-1, IEC/EN 60947-1
- Illuminable Yes
- Probing possible Yes
- Colour of the front ring Silver
- Design Round
- Material of the operators Glass
- Sealing type Membrane, Lip gaskets, Form seals
- Material of the front ring Aluminium
- Installation conditions (mechanical) arbitrarily
- Colour of the operating element Blue
- Versions Flush-mounted illuminated pushbutton - Front plate mounting
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
RDLMBL Description
RDLMBL Schmersal - Command and signalling devices; "R" program; Illuminated pushbutton with membrane; Symbols still clearly visible under transparent membrane
Related documents RDLMBL Specs
