56521 Murr Elektronik I/O Systems

56521 on Applied Automation
Murr Elektronik

Part#:56521

Manufacturer:Murr Elektronik

Category:I/O Systems

Product Lifecycle:Active

Get a quick Quote!

56521 Murrelektronik - CUBE67+ BUSNODE, Profibus DP, Cube67+ BN-P

About the manufacturer: Murr Elektronik is one of the manufacturers that offers I/O Systems that you can order at Applied Automation site. Murrelektronik is a worldwide frontrunner in creating, producing, and distributing automation solutions. Our product offerings are categorized into four main lines: Power Supplies and Control, Interfaces, Cables/Connectors, and IO Systems.

Check out the 56521 Murr Elektronik price in the box on the right side or send a quick quote.

Product Details

  • Weight
    418.18 g
  • Series
    Field Bus System
  • Monitoring - no voltage
    yes
  • Short-circuit and overload
    yes
  • Communication status
    via LED and BUS
  • Monitoring - under voltage
    yes
  • Diagnostic via BUS
    per module and channel
  • Diagnostic via LED
    per module and channel
  • Product article number of manufacturer
    56521
  • Internal system connection
    4× M12 (female) A-coded, 6-pole, 2× max. 4 A
  • Machine Option Management
    yes
  • No. of masterports (IO-Link)
    max. 12
  • Fieldbus
    PROFIBUS 12 Mbit/s; M12, B-coded
  • Current consumption
    max. 120 mA
  • Sensor-system/actuator supply
    7/8", 5-pole, 2× max. 8 A
  • I/O capacity
    max. 244 Byte (Input), max. 244 Byte (Output)
  • Module capacity
    max. 32
  • Addressing
    Rotary switch 0...99
  • Operating voltage
    24 V DC (EN 61131-2)
  • Protection
    IP67
  • Mounting method
    2-hole screw mounting
  • Temperature range
    0...+55 °C (storage temperature -20...+75 °C)
  • Dimensions H×W×D
    151×62×40.5 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

56521 Description

56521 Murrelektronik - CUBE67+ BUSNODE, Profibus DP, Cube67+ BN-P

Related documents 56521 Specs

56521 DataSheet.pdf
