10571 Murr Elektronik Line Filters & Conditioners

Name: 10571
Brand: Murr Elektronik
Price: 455.5 USD
Availability: BackOrder

Part#:10571

Manufacturer:Murr Elektronik

Category:Line Filters & Conditioners

Product Lifecycle:Active

Get a quick Quote!

10571 Murrelektronik - MEF EMC-FILTER 3-PHASE 1-STAGE WITH NEUTRAL, I:10A U:4x500 VAC, With increased attenuation

About the manufacturer: Murr Elektronik is one of the manufacturers that offers Line Filters & Conditioners that you can order at Applied Automation site. Murrelektronik is a worldwide frontrunner in creating, producing, and distributing automation solutions. Our product offerings are categorized into four main lines: Power Supplies and Control, Interfaces, Cables/Connectors, and IO Systems.

Check out the 10571 Murr Elektronik price in the box on the right side or send a quick quote.

Product Details

Weight
1000 g
Series
Filter Modules
Functional description
The 3-phase and one-stage EMC filters MEF 3/1 are used in the range 0.1...30 MHz and dampen interferences found in cables from the mains, supply units and control systems. They are suitable for TN-S, TN-C-S, and TT networks. The best results are obtained
Product article number of manufacturer
10571
Connection cross section
0.2...10 mm² single core (AWG 24...7); 0.2...6 mm² multiple core (AWG 24...9)
Operating frequency
50...60 Hz
Climatic category
25/085/21 (EN 60068-1)
Overload current
18× (IN t) max. 0.5 ms; 1.5× (IN t) max. 1 min. (1× per hour)
Dimensions H×W×D
153×130×100 mm
Test isolation voltage
3.3 kV (L-N), 2 s; 3.1 kV (L-L), 2 s
Operating voltage
max. 3× 500 V AC
Consumption
max. 15 mA (250 V AC)
Mounting method
screw fixing, M6
