Panasonic AFP0RE8YT is an I/O unit categorized under the Expansion Units sub-range, designed specifically as a DC digital output unit for right-side expansion. It features a MIL connector for its connection type and is suitable for DIN rail mounting. This unit is equipped with 8 digital outputs, each operating at 24Vdc with NPN transistor output type, capable of handling up to 300mA.

Panasonic AFP87423 is an I/O unit designed as an FP remote output unit. It operates with a supply voltage of 24Vdc and features 8 digital outputs, each capable of 24Vdc with transistor output type, supporting up to 500mA.

Panasonic AFPX-E30RD is an I/O unit categorized under the expansion units sub-range, designed to function as a DC digital mixed input and output unit or cassette. It operates with a supply voltage of 24Vdc and features screw-clamp terminal connections for secure installation. This unit is suitable for DIN rail mounting, ensuring easy integration into various control systems. It is equipped with 16 digital inputs that support both sink and source types at 24Vdc, and 14 digital outputs, which are of the NO (Normally Open) contact type and can handle up to 2A.

Panasonic AFPX-DA2 is an I/O unit categorized under the add-on cassettes sub-range, designed to function as an analog output (D/A converter) unit or cassette. It features screw-clamp terminal connections for secure installation and is suitable for DIN rail mounting. This unit is equipped with 2 analog outputs, supporting both 0-10Vdc and 0-20mA signals with a 1/4096 conversion resolution. It boasts a response time of 2ms across 2 channels, which are insulated, translating to a response speed of 0.002 seconds.

Panasonic AFPX-A21 is an I/O unit categorized under the add-on cassettes sub-range, designed for analog mixed input and output functions with an A/D - D/A converter unit or cassette. It features screw-clamp terminal connections and is suitable for DIN rail mounting. This unit provides 1 x analog output with a 0-10Vdc / 0-20mA range and a 1/4096 conversion resolution. It offers a response time of 2ms for 2 channels with insulated inputs and 1ms for 1 channel with an insulated output. Additionally, it includes 2 x analog inputs supporting 0-5Vdc, 0-10Vdc, and 0-20mA ranges.

Panasonic AFPRP1XY16D2T is an I/O unit within the PHLS sub-range, designed as a remote slave mixed DC input and output unit. It features screw-clamp terminal connections and has a standard shape. The unit is equipped with 8 digital inputs (24Vdc) with 1 common polarity and 8 digital outputs (24Vdc sink transistor; 100mA).

Panasonic AFP7X32D2 is an I/O unit designed for DC digital input with a common polarity +/- and common input time constant setting feature. It utilizes a MIL connector for its connection type and is mounted using a DIN rail. This unit is equipped with 32 digital inputs that operate at 24Vdc.

Panasonic AFP7PP02T is an I/O unit designed for position control, capable of handling 1pps to 500kpps with functions including linear and circular interpolation, as well as electronic cam and electronic gear for 2-axes with transistor output. It is designed for DIN rail mounting, facilitating easy integration into various automation systems.

Panasonic AFP7PP04L is an I/O unit designed for position control, capable of handling 1pps to 4Mpps with functionalities including linear and circular interpolation types, as well as electronic cam and electronic gear features for up to 4 axes with line driver output. It is designed for DIN rail mounting, facilitating easy integration into various automation systems.

Panasonic AFP7PG04T is an I/O unit designed for pulse output functions, capable of delivering 1pps to 500kpps. It features startup using I/O contact and includes built-in limit (+) and limit (-) functionalities, along with a servo ON output. The unit operates on a supply voltage range of 21.6Vdc to 26.4Vdc, with a nominal voltage of 24Vdc. It is equipped with 4 digital outputs, which are transistor outputs supporting 1 to 500kpps.
