126.052.15 Werma Buzzers

Product Details

• ICAO Certification
  No
• Conforms with RoHS CN
  No
• Conforms with VdS
  No
• Conforms with AS-I
  No
• Conforms with GL
  No
• Conforms with FCC
  No
• Conforms with CCC
  No
• EAC certificate available
  Yes
• Conforms with UL
  No
• Conforms with IC
  No
• Conform with ATEX-directive
  No
• WEEE
  Yes
• Acoustic service life
  1,000 h minimum
• Number of tones
  4 tone
• Volume (max) at 1m distance
  105,0 dB (A)
• Request to external PSU
  SELV/PELV
• Conforms with CE
  Yes
• Pollution degree
  2
• Protection class
  Protection class 3
• Rated operational current
  80 mA
Rated inrush current
<500mA
Rated operational voltage
24 VDC
Operating voltage type
DC
Operating voltage tolerance
+/- 10%
Product weight
105 g
Operating voltage
12-24V
Working temperature maximum
+50°C
Weight with packaging
131 g
Height
80 mm
Working temperature minimum
-20°C
Cable entry maximum
d = 9 mm
Type of fixing
Wall mounting
Materials
PC/ABS
cross-sectional area maximum
1,50mm² / 16AWG
Protection category
IP33
Housing colour
Grey
Cable entry
Through hole
Diameter
70 mm
Connection
Screw terminals
