35018ET3GRB449T-W22 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  460 V
• Output Rating
  350 HP
• Rated Speed
  1785 rpm
• Flange Type
  Without
• Voltage
  460 V
• Enclosure
  IC411 - TEFC
• Degree of Protection
  IP55
• Rated torque
  1030 ft.lb
• L. R. Amperes
  3192 A
• Number of poles
  4
• Terminal box¹
  Left position
• Flange
  Without
• Synchronous speed
  1800 rpm
• Output rating
  350 HP
• Standard
  NEMA MG-1
• Approx. weight³
  3063 lb
• Noise level²
  75.0 dB(A)
• Service factor
  1.15
• Starting Method
  Direct On Line
Altitude
1000 m.a.s.l.
Mounting
F-1
Ambient temperature
-20°C to +40°C
Rotation¹
Both (CW and CCW)
Temperature rise
80 K
Duty Cycle
Cont.(S1)
No load current
135 A
Locked rotor torque
280 %
Moment of inertia (J)
118 sq.ft.lb
Design
A
Insulation Class
F
Locked rotor time
25s (cold) 14s (hot)
Breakdown torque
280 %
LRC
8.0x(Code J)
Rated current
399 A
Frame
447/9T
Rated speed
1785 rpm
Rated voltage
460 V
Output
350 HP (260 kW)
Slip
0.83 %
Frequency
60 Hz
Number of Poles
4
