20018OT3G445TSDF2-W4 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  460 V
• Output Rating
  200 HP
• Rated Speed
  1783 rpm
• Flange Type
  D
• Terminal box¹
  Right position
• Output rating
  200 HP
• Flange
  D
• Synchronous speed
  1800 rpm
• Number of poles
  4
• Voltage
  460//380 V
• Standard
  NEMA MG-1
• Approx. weight³
  1421 lb
• Altitude
  1000 m.a.s.l.
• Enclosure
  IC01 - ODP
• Ambient temperature
  -20°C to +40°C
• Noise level²
  78.0 dB(A)
• Mounting
  F-2
• Rotation¹
  Both (CW and CCW)
• Duty Cycle
  Cont.(S1)
Degree of Protection
IP23
Starting Method
Direct On Line
Temperature rise
80 K
Service factor
1.15
Design
B
Insulation Class
F
Locked rotor torque
210 %
Breakdown torque
250 %
Rated torque
589 ft.lb
Locked rotor time
25s (cold) 14s (hot)
Moment of inertia (J)
46.4 sq.ft.lb
No load current
86.5 A
Frame
444/5TSD
LRC
6.6x(Code G)
Rated voltage
460 V
Output
200 HP (150 kW)
Rated speed
1783 rpm
Slip
0.94 %
Rated current
234 A
L. R. Amperes
1544 A
Frequency
60 Hz
Number of Poles
4
