15009ET3GKD447T-W22 WEG AC Motors

Product Details

• Number of Poles
  8 Pole
• Voltage
  460 V
• Output Rating
  150 HP
• Rated Speed
  890 rpm
• Flange Type
  Without
• L. R. Amperes
  1216 A
• Rated current
  187 A
• Terminal box¹
  Left position
• Output rating
  150 HP
• Flange
  Without
• Number of poles
  8
• Synchronous speed
  900 rpm
• Voltage
  460 V
• Approx. weight³
  2287 lb
• Rotation¹
  Both (CW and CCW)
• Standard
  NEMA MG-1
• Degree of Protection
  IP55
• Noise level²
  63.0 dB(A)
• Enclosure
  IC411 - TEFC
• Mounting
  F-1
Duty Cycle
Cont.(S1)
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Ambient temperature
-20°C to +40°C
Temperature rise
105 K
Service factor
1.15
Insulation Class
F
Design
A
Moment of inertia (J)
126 sq.ft.lb
Breakdown torque
229 %
LRC
6.5x(Code H)
Rated torque
885 ft.lb
Locked rotor time
27s (cold) 15s (hot)
No load current
85.0 A
Locked rotor torque
200 %
Rated speed
890 rpm
Frame
445/7T
Output
150 HP (110 kW)
Rated voltage
460 V
Frequency
60 Hz
Number of Poles
8
Slip
1.11 %
