12894799 WEG AC Motors

Product Details

• Terminal box¹
  Left position
• Flange
  C
• Output rating
  1 HP
• Number of poles
  4
• Synchronous speed
  1800 rpm
• Voltage
  230/460//190-220/380-415 V
• Standard
  NEMA MG-1
• Approx. weight³
  27.9 lb
• Starting Method
  Direct On Line
• Rotation¹
  Both (CW and CCW)
• Noise level²
  52.0 dB(A)
• Enclosure
  IC411 - TEFC
• Mounting
  F-1
• Ambient temperature
  -20°C to +40°C
• Duty Cycle
  Cont.(S1)
• Altitude
  1000 m.a.s.l.
• Temperature rise
  80 K
• Degree of Protection
  IP55
• Insulation Class
  F
• Service factor
  1.15 (1.00 @ 208V)
Moment of inertia (J)
0.0842 sq.ft.lb
Design
A
L. R. Amperes
25.6/12.8 A
Locked rotor torque
270 %
Breakdown torque
300 %
Locked rotor time
21s (cold) 12s (hot)
No load current
2.40/1.20 A
Rated current
3.32/1.66 A
LRC
7.7x(Code M)
Rated voltage
230/460 V
Rated torque
2.98 ft.lb
Slip
2.22 %
Frame
56C
Frequency
60 Hz
Number of Poles
4
Output
1 HP (0.75 kW)
Rated speed
1760 rpm
