12518ET3E444TC-W22 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  125 HP
• Rated Speed
  1785 rpm
• Flange Type
  C
• Terminal box¹
  Left position
• Synchronous speed
  1800 rpm
• Noise level²
  73.0 dB(A)
• Number of poles
  4
• Flange
  C
• Voltage
  230/460//380 V
• Output rating
  125 HP
• Ambient temperature
  -20°C to +40°C
• Standard
  NEMA MG-1
• Approx. weight³
  1564 lb
• Degree of Protection
  IP55
• Rotation¹
  Both (CW and CCW)
• Enclosure
  IC411 - TEFC
• Duty Cycle
  Cont.(S1)
• Locked rotor time
  48s (cold) 27s (hot)
Starting Method
Direct On Line
Mounting
F-1
Altitude
1000 m.a.s.l.
Temperature rise
80 K
Service factor
1.15
No load current
92.0/46.0 A
Locked rotor torque
200 %
Design
B
Moment of inertia (J)
57.2 sq.ft.lb
Breakdown torque
229 %
Insulation Class
F
Rated torque
368 ft.lb
Rated speed
1785 rpm
LRC
6.5x(Code G)
Frequency
60 Hz
Output
125 HP
Number of Poles
4
Rated current
279/139 A
Slip
0.83 %
L. R. Amperes
1811/905 A
Rated voltage
230/460 V
Frame
444/5TC
