07536ST3QIE365TS-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 460 V
- Output Rating 75 HP
- Rated Speed 3550 rpm
- Flange Type Without
- Terminal box¹ Left position
- Flange Without
- Output rating 75 HP
- Standard NEMA MG-1
- Approx. weight³ 907 lb
- Number of poles 2
- Synchronous speed 3600 rpm
- Voltage 460 V
- Noise level² 79.0 dB(A)
- Mounting F-1
- Enclosure IC411 - TEFC
- Rotation¹ Both (CW and CCW)
- Degree of Protection IP56
- Altitude 1000 m.a.s.l.
- Ambient temperature -20°C to +40°C
- Temperature rise 80 K
- Starting Method Direct On Line
- Duty Cycle Cont.(S1)
- Service factor 1.25
- Locked rotor time 18s (cold) 10s (hot)
- Insulation Class F
- Design B
- Rated torque 111 ft.lb
- No load current 19.0 A
- Moment of inertia (J) 11.9 sq.ft.lb
- Locked rotor torque 220 %
- Breakdown torque 270 %
- Number of Poles 2
- Frame 364/5TS
- LRC 6.6x(Code G)
- Frequency 60 Hz
- Slip 1.39 %
- Output 75 HP (55 kW)
- Rated voltage 460 V
- Rated current 81.9 A
- L. R. Amperes 541 A
- Rated speed 3550 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
