07518ET3E365T-W22 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  75 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• Terminal box¹
  Left position
• Noise level²
  67.0 dB(A)
• Synchronous speed
  1800 rpm
• Flange
  Without
• Number of poles
  4
• Output rating
  75 HP
• Voltage
  230/460//380 V
• Rotation¹
  Both (CW and CCW)
• Mounting
  F-1
• Standard
  NEMA MG-1
• Enclosure
  IC411 - TEFC
• Ambient temperature
  -20°C to +40°C
• Degree of Protection
  IP55
• Starting Method
  Direct On Line
• Duty Cycle
  Cont.(S1)
Altitude
1000 m.a.s.l.
Moment of inertia (J)
23.3 sq.ft.lb
LRC
6.4x(Code G)
Service factor
1.25
Locked rotor time
25s (cold) 14s (hot)
Breakdown torque
260 %
Design
B
Number of Poles
4
Insulation Class
F
No load current
66.0/33.0 A
Locked rotor torque
240 %
Slip
1.11 %
Rated torque
221 ft.lb
Frame
364/5T
Rated speed
1780 rpm
Rated voltage
230/460 V
Rated current
174/87.2 A
Output
75 HP (55 kW)
L. R. Amperes
1116/558 A
Approx. weight³
934 lb
Temperature rise
80 K
Frequency
60 Hz
