05009ET3E404T-W22 WEG AC Motors

Product Details

• Number of Poles
  8 Pole
• Voltage
  230/460 V
• Output Rating
  50 HP
• Rated Speed
  880 rpm
• Flange Type
  Without
• Terminal box¹
  Left position
• Flange
  Without
• Output rating
  50 HP
• Synchronous speed
  900 rpm
• Number of poles
  8
• Voltage
  230/460//380 V
• Approx. weight³
  1117 lb
• Standard
  NEMA MG-1
• Rotation¹
  Both (CW and CCW)
• Noise level²
  60.0 dB(A)
• Mounting
  F-1
• Enclosure
  IC411 - TEFC
• Degree of Protection
  IP55
• Altitude
  1000 m.a.s.l.
• Ambient temperature
  -20°C to +40°C
Starting Method
Direct On Line
Service factor
1.25
Temperature rise
80 K
Duty Cycle
Cont.(S1)
Insulation Class
F
Design
B
Moment of inertia (J)
34.6 sq.ft.lb
Locked rotor time
52s (cold) 29s (hot)
Locked rotor torque
170 %
Rated torque
298 ft.lb
No load current
49.0/24.5 A
Breakdown torque
260 %
LRC
7.2x(Code H)
Frequency
60 Hz
Rated speed
880 rpm
Output
50 HP (37 kW)
Frame
404/5T
Number of Poles
8
Rated voltage
230/460 V
Slip
2.22 %
Rated current
120/60.2 A
L. R. Amperes
867/433 A
