04018EG3E324T-W22 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  40 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• Terminal box¹
  Left position
• Output rating
  40 HP
• Flange
  Without
• Synchronous speed
  1800 rpm
• Voltage
  208-230/460//380 V
• Standard
  NEMA MG-1
• Number of poles
  4
• Approx. weight³
  593 lb
• Rotation¹
  Both (CW and CCW)
• Noise level²
  66.0 dB(A)
• Ambient temperature
  -20°C to +40°C
• Degree of Protection
  IP55
• Altitude
  1000 m.a.s.l.
• Starting Method
  Direct On Line
• Enclosure
  IC411 - TEFC
Duty Cycle
Cont.(S1)
Temperature rise
80 K
Mounting
F-1
Breakdown torque
350 %
Service factor
1.25
Locked rotor time
39s (cold) 22s (hot)
Insulation Class
F
Moment of inertia (J)
8.83 sq.ft.lb
Design
A
Rated torque
118 ft.lb
LRC
8.4x(Code K)
Locked rotor torque
320 %
No load current
44.0/22.0 A
Rated voltage
230/460 V
Number of Poles
4
Frame
324/6T
Output
40 HP (30 kW)
Slip
1.11 %
Rated current
97.8/48.9 A
Frequency
60 Hz
L. R. Amperes
822/411 A
Rated speed
1780 rpm
