03089EP3QCT326V2-W22 WEG AC Motors
Product Details
- Number of Poles 45508 Pole
- Voltage 460 V
- Output Rating 7.5/30 HP
- Rated Speed 1780 rpm
- Flange Type Without
- Terminal box¹ Right position
- Number of poles 8/4
- Approx. weight³ 596 lb
- Noise level² 69.0 dB(A)
- Standard NEMA MG-1
- Duty Cycle Cont.(S1)
- Service factor 1.15
- Frame 324/6T
- Synchronous speed 900/1800 rpm
- Flange Without
- Output rating 7.5/30 HP
- Voltage 460 V
- Degree of Protection IP55
- Mounting F-2
- Enclosure IC411 - TEFC
- Rotation¹ Both (CW and CCW)
- Ambient temperature -20°C to +40°C
- Altitude 1000 m.a.s.l.
- Starting Method Direct On Line
- Temperature rise 80 K
- Locked rotor time 27s (cold) 15s (hot)
- Moment of inertia (J) 9.16 sq.ft.lb
- Breakdown torque 280 %
- Locked rotor torque 220 %
- Insulation Class F
- No load current 13.0 A
- Rated torque 88.5 ft.lb
- LRC 7.8x(Code J)
- Frequency 60 Hz
- Slip 1.11 %
- Rated current 37.3 A
- Output 30 HP (22 kW)
- L. R. Amperes 291 A
- Rated voltage 460 V
- Number of Poles 8/4
- Rated speed 1780 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
