02518ET3ECT284TF1-W2 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  25 HP
• Rated Speed
  1770 rpm
• Flange Type
  Without
• Flange
  Without
• Terminal box¹
  Left position
• Output rating
  25 HP
• Synchronous speed
  1800 rpm
• Number of poles
  4
• Voltage
  230/460//380 V
• Noise level²
  63.0 dB(A)
• Degree of Protection
  IP55
• Enclosure
  IC411 - TEFC
• Standard
  NEMA MG-1
• Approx. weight³
  391 lb
• Mounting
  F-1
• Altitude
  1000 m.a.s.l.
• Rotation¹
  Both (CW and CCW)
• Ambient temperature
  -20°C to +40°C
Starting Method
Direct On Line
Temperature rise
80 K
Duty Cycle
Cont.(S1)
Insulation Class
F
Service factor
1.25
Design
B
Locked rotor torque
240 %
Rated torque
74.2 ft.lb
LRC
6.2x(Code G)
Moment of inertia (J)
5.11 sq.ft.lb
Locked rotor time
43s (cold) 24s (hot)
Breakdown torque
270 %
Slip
1.67 %
No load current
22.0/11.0 A
Frame
284T
Frequency
60 Hz
Number of Poles
4
Rated voltage
230/460 V
Rated current
59.0/29.5 A
Output
25 HP (18.5 kW)
L. R. Amperes
366/183 A
Rated speed
1770 rpm
