01036OT3H213TC-S WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  575 V
• Output Rating
  10 HP
• Rated Speed
  3535 rpm
• Flange Type
  C
• Flange
  C
• Terminal box¹
  Left position
• Synchronous speed
  3600 rpm
• Number of poles
  2
• Output rating
  10 HP
• Voltage
  575 V
• Noise level²
  66.0 dB(A)
• Standard
  NEMA MG-1
• Approx. weight³
  125 lb
• Rotation¹
  Both (CW and CCW)
• Mounting
  F-1
• Enclosure
  IC01 - ODP
• Altitude
  1000 m.a.s.l.
• Ambient temperature
  -20°C to +40°C
• Starting Method
  Direct On Line
Duty Cycle
Cont.(S1)
Moment of inertia (J)
0.4651 sq.ft.lb
Temperature rise
80 K
Service factor
1.15
Design
B
No load current
3.73 A
Insulation Class
F
Locked rotor time
19s (cold) 11s (hot)
Breakdown torque
280 %
Locked rotor torque
200 %
Rated torque
14.9 ft.lb
LRC
6.8x(Code H)
Rated speed
3535 rpm
Number of Poles
2
Frequency
60 Hz
Output
10 HP (7.5 kW)
L. R. Amperes
65.3 A
Rated current
9.60 A
Slip
1.81 %
Rated voltage
575 V
Frame
213/5TC
