00789EP3QCT254V2-W22 WEG AC Motors

Product Details

• Number of Poles
  45508 Pole
• Voltage
  460 V
• Output Rating
  1.75/7.5 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• L. R. Amperes
  79.1 A
• Starting Method
  Direct On Line
• Terminal box¹
  Right position
• Flange
  Without
• Synchronous speed
  900/1800 rpm
• Noise level²
  64.0 dB(A)
• Approx. weight³
  2.2 lb
• Number of poles
  8/4
• Standard
  NEMA MG-1
• Output rating
  1.75/7.5 HP
• Ambient temperature
  -20°C to +40°C
• Voltage
  460 V
• Mounting
  F-2
• Rotation¹
  Both (CW and CCW)
• Altitude
  1000 m.a.s.l.
Enclosure
IC411 - TEFC
Duty Cycle
Cont.(S1)
Service factor
1.15
Locked rotor time
32s (cold) 18s (hot)
Insulation Class
F
Temperature rise
80 K
Degree of Protection
IP55
Moment of inertia (J)
2.62 sq.ft.lb
Breakdown torque
360 %
Rated torque
22.1 ft.lb
No load current
3.55 A
LRC
8.5x(Code K)
Locked rotor torque
260 %
Rated current
9.30 A
Rated voltage
460 V
Output
7.5 HP (5.5 kW)
Slip
1.11 %
Rated speed
1780 rpm
Frame
254T
Frequency
60 Hz
Number of Poles
8/4
