00309ST3HIE215T-W22 WEG AC Motors

Product Details

• Number of Poles
  8 Pole
• Voltage
  575 V
• Output Rating
  3 HP
• Rated Speed
  870 rpm
• Flange Type
  Without
• Output rating
  3 HP
• Flange
  Without
• Synchronous speed
  900 rpm
• Terminal box¹
  Left position
• Voltage
  575 V
• Standard
  NEMA MG-1
• Number of poles
  8
• Approx. weight³
  188 lb
• Enclosure
  IC411 - TEFC
• Mounting
  F-1
• Noise level²
  52.0 dB(A)
• Rotation¹
  Both (CW and CCW)
• Ambient temperature
  -20°C to +40°C
• Degree of Protection
  IP56
• Starting Method
  Direct On Line
Altitude
1000 m.a.s.l.
Duty Cycle
Cont.(S1)
Temperature rise
80 K
Insulation Class
F
LRC
6.8x(Code K)
Design
B
No load current
2.40 A
Rated torque
18.1 ft.lb
Breakdown torque
300 %
Service factor
1.25
Locked rotor time
79s (cold) 44s (hot)
Moment of inertia (J)
2.11 sq.ft.lb
Locked rotor torque
220 %
Rated voltage
575 V
L. R. Amperes
25.1 A
Rated speed
870 rpm
Rated current
3.69 A
Frequency
60 Hz
Slip
3.33 %
Output
3 HP (2.2 kW)
Number of Poles
8
Frame
213/5T
