00136ET3EW56CFL-S WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  230/460 V
• Output Rating
  1 HP
• Rated Speed
  3435 rpm
• Flange Type
  C
• Terminal box¹
  Left position
• Number of poles
  2
• Flange
  C
• Synchronous speed
  3600 rpm
• Output rating
  1 HP
• Voltage
  230/460//190-220/380-415 V
• Standard
  NEMA MG-1
• Rotation¹
  Both (CW and CCW)
• Approx. weight³
  21.5 lb
• Noise level²
  65.0 dB(A)
• Enclosure
  IC411 - TEFC
• Mounting
  F-1
• Ambient temperature
  -20°C to +40°C
• Starting Method
  Direct On Line
• Degree of Protection
  IP55
Duty Cycle
Cont.(S1)
Altitude
1000 m.a.s.l.
Service factor
1.15 (1.00 @ 208V)
Insulation Class
F
Breakdown torque
380 %
Locked rotor time
18s (cold) 10s (hot)
Temperature rise
80 K
Locked rotor torque
360 %
Moment of inertia (J)
0.0254 sq.ft.lb
Rated torque
1.53 ft.lb
No load current
1.60/0.798 A
LRC
8.8x(Code M)
Rated voltage
230/460 V
Output
1 HP (0.75 kW)
Number of Poles
2
Rated current
3.00/1.50 A
Rated speed
3435 rpm
Frequency
60 Hz
Slip
4.58 %
Frame
W56C
L. R. Amperes
26.4/13.2 A
