00112ET3E56C-S WEG AC Motors

Product Details

• Number of Poles
  6 Pole
• Voltage
  230/460 V
• Output Rating
  1 HP
• Rated Speed
  1145 rpm
• Flange Type
  C
• Output rating
  1 HP
• Terminal box¹
  Left position
• Flange
  C
• Synchronous speed
  1200 rpm
• Number of poles
  6
• Standard
  NEMA MG-1
• Noise level²
  50.0 dB(A)
• Voltage
  230/460//190-220/380-415 V
• Approx. weight³
  38.7 lb
• Rotation¹
  Both (CW and CCW)
• Enclosure
  IC411 - TEFC
• Mounting
  F-1
• Insulation Class
  F
• Temperature rise
  80 K
• Degree of Protection
  IP55
Duty Cycle
Cont.(S1)
Service factor
1.15 (1.00 @ 208V)
Ambient temperature
-20°C to +40°C
Design
B
Altitude
1000 m.a.s.l.
Starting Method
Direct On Line
Moment of inertia (J)
0.1597 sq.ft.lb
Locked rotor torque
229 %
Breakdown torque
280 %
LRC
5.8x(Code J)
Locked rotor time
55s (cold) 31s (hot)
No load current
2.03/1.01 A
Rated torque
4.59 ft.lb
Frequency
60 Hz
Number of Poles
6
Rated current
3.16/1.58 A
Rated speed
1145 rpm
L. R. Amperes
18.3/9.16 A
Slip
4.58 %
Output
1 HP (0.75 kW)
Rated voltage
230/460 V
Frame
56HC
