.7536ES3H56-S WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  575 V
• Output Rating
  0.75 HP
• Rated Speed
  3475 rpm
• Flange Type
  Without
• Flange
  Without
• Terminal box¹
  Left position
• Output rating
  0.75 HP
• Synchronous speed
  3600 rpm
• Number of poles
  2
• Approx. weight³
  20.9 lb
• Voltage
  575 V
• Standard
  NEMA MG-1
• Noise level²
  68.0 dB(A)
• Rotation¹
  Both (CW and CCW)
• Altitude
  1000 m.a.s.l.
• Mounting
  F-1
• Enclosure
  IC411 - TEFC
• Ambient temperature
  -20°C to +40°C
• Degree of Protection
  IP55
Starting Method
Direct On Line
Temperature rise
80 K
Duty Cycle
Cont.(S1)
Service factor
1.15
Insulation Class
F
Moment of inertia (J)
0.0517 sq.ft.lb
Breakdown torque
290 %
Locked rotor time
41s (cold) 23s (hot)
Locked rotor torque
250 %
Rated torque
1.13 ft.lb
LRC
7.0x(Code K)
No load current
0.440 A
L. R. Amperes
6.33 A
Number of Poles
2
Rated speed
3475 rpm
Slip
3.47 %
Rated voltage
575 V
Output
0.75 HP (0.55 kW)
Rated current
0.904 A
Frequency
60 Hz
Frame
56
