ZS 236-11Z-M20 Schmersal Electronic Components

Product Details

• Switchover time, maximum
  5.5 ms
• Bounce duration, maximum
  3 ms
• Switching frequency
  5,000 /h
• Switching element
  NO contact, NC contact
• Required rated short-circuit current to EN 60947-5-1
  1,000 A
• Switching principle
  Snap switch element
• Utilisation category AC-15
  4 A
• Rated impulse withstand voltage Uimp
  6 kV
• Thermal test current
  10 A
• Utilisation category DC-13
  1 A
• Rated insulation voltage Ui
  250 V
• Note (Cable section)
  All indications about the cable section are including the conductor ferrules.
• Ambient temperature, maximum
  +80 °C
• Length of sensor
  30 mm
• Degree of protection
  IP65 to EN 60529, IP67 to EN 60529
• Height of sensor
  73.5 mm
• Width of sensor
  30 mm
• Cable section, maximum
  2.5 mm²
• Ambient temperature, minimum
  -30 °C
• Actuating force, minimum
  9 N
Mechanical life, minimum
20,000,000 Operations
Positive break force, minimum
19 N
Terminal Connector
Screw connection
Cable section, minimum
0.75 mm²
Actuating speed, maximum
1 m/s
Actuating speed, minimum
10 mm/min
Actuating element
Plunger
Material of the contacts, electrical
Silver
Safety functions
Yes
Standards
IEC 60947-5-1, EN ISO 13849-1, BG-GS-ET-15
Enclosure material
Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
Actuator type to DIN EN 50047
B
Number of safety contacts
1
Number of auxiliary contacts
1
Housing construction form
Norm construction design
Gross weight
52 g
