TESK-LA-12ST1 Schmersal Safety Switches
Part#:TESK-LA-12ST1
Manufacturer:Schmersal
Category:Safety Switches
Alt. Part#:103005721
Product Lifecycle:Active
Get a quick Quote!
TESK-LA-12ST1 Schmersal - Safety switch for hinged guards; Hinge safety switch; connector plug M12 bottom; with fixed switching angle; pre-set for front mounting; long hinge part; Metal enclosure
About the manufacturer: Schmersal is one of the manufacturers that offers Safety Switches that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the TESK-LA-12ST1 Schmersal price in the box on the right side or send a quick quote.
Product Details
- Switching frequency 1,200 /h
- Switching element NO contact, NC contact
- Utilisation category AC-15 2 A
- Thermal test current 2.5 A
- Rated insulation voltage Ui 30 V
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Degree of protection IP65
- Width of sensor 98 mm
- Ambient temperature, minimum -25 °C
- Colour of the housing Silver
- Mechanical life, minimum 1,000,000 Operations
- Switching principle Creep circuit element
- Utilisation category DC-13 1 A
- Rated impulse withstand voltage Uimp 0.5 kV
- Ambient temperature, maximum +65 °C
- Length of sensor 20 mm
- Height of sensor 116 mm
- Cable section, minimum 0.5 mm²
- Cable section, maximum 1 mm²
- Terminal Connector Connector M12
- Mounting outside Yes
- Gross weight 371.3 g
- Number of auxiliary contacts 1
- Alignment aid Yes
- Number of safety contacts 2
- Material of the contacts, electrical Silver-nickel alloy 10
- Enclosure material Zinc die-cast
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
TESK-LA-12ST1 Description
TESK-LA-12ST1 Schmersal - Safety switch for hinged guards; Hinge safety switch; connector plug M12 bottom; with fixed switching angle; pre-set for front mounting; long hinge part; Metal enclosure
