SLB440-ER-1-LST Schmersal Safety Light Curtains

SLB440-ER-1-LST on Applied Automation
Schmersal

Part#:SLB440-ER-1-LST

Manufacturer:Schmersal

Alt. Part#:103013525

Product Lifecycle:Active

Get a quick Quote!

SLB440-ER-1-LST Schmersal - Safety light barriers; SLB 440 Series -; Compact design With integral evaluation; Height range 75 m (Reserve up to 90 m); Safe OSSD outputs to PLe; Automatic start or restart interlock; Sturdy metal enclosure with M12 connector or cable; Version with heat

About the manufacturer: Schmersal is one of the manufacturers that offers Safety Light Curtains that you can order at Applied Automation site. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.

Check out the SLB440-ER-1-LST Schmersal price in the box on the right side or send a quick quote.

Product Details

  • Electrical power consumption of the transmitter, maximum
    5 W
  • Versions
    p-type
  • Length of cable, maximum
    100 m
  • Switching voltage OSSD, HIGH signal
    24 V
  • Output current, (fail-safe output), maximum
    0.2 A
  • Electrical power consumption of the receiver, maximum
    5 W
  • Protection rating
    III
  • Storage and transport temperature, maximum
    +70 °C
  • Voltage type
    DC (direct current)
  • Degree of protection
    IP67 to EN 60529
  • Ambient temperature, minimum
    -30 °C
  • Storage and transport temperature, minimum
    -30 °C
  • Ambient temperature, maximum
    +50 °C
  • Width
    27.8 mm
  • Height
    72 mm
  • Length
    33 mm
  • Terminal, Connector, Transmitter
    Cable with connector plug M12, 4-pole
  • Range, protection field, minimum
    300 mm
  • Terminal connector, Recipient
    Cable with connector plug M12, 5-pole
  • Wave length of the sensor
    880 nm
  • Range, protection field, maximum
    15,000 mm
  • Detection ability for test bodies at v = 1.6 m/s
    40 mm
  • Number of fail-safe digital outputs
    2
  • Integral System Diagnostics
    Yes
  • Number of beams
    1
  • Standards
    EN 61496-1, EN 61496-2
  • Integral System Diagnostics, status
    Yes
  • Restart interlock (manual reset)
    Yes
  • Reaction time, maximum
    22 ms
  • Gross weight
    180 g
  • Coding, light barrier beam
    1
  • Reaction time, minimum
    7 ms
  • Beam coding available
    Yes
  • Enclosure material
    Aluminium

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


SLB440-ER-1-LST Description

SLB440-ER-1-LST Schmersal - Safety light barriers; SLB 440 Series -; Compact design With integral evaluation; Height range 75 m (Reserve up to 90 m); Safe OSSD outputs to PLe; Automatic start or restart interlock; Sturdy metal enclosure with M12 connector or cable; Version with heat
