RMLHWS Schmersal Indicator Lights

Product Details

• Ambient temperature, maximum
  +75 °C
• Thickness of the front panel, maximum
  6 mm
• Ambient temperature, minimum
  -25 °C
• Spacing
  40 x 50 mm
• Thickness, of the front panel, minimum
  1 mm
• Degree of protection
  IP65
• Diameter hole
  22.3 mm
• Diameter hole, with tolerance indication
  22.3 + 0.4 mm
• Diameter of the dome
  22 mm
• Diameter of the front ring
  39.5 mm
• Installation conditions (mechanical)
  arbitrarily
• Height of the dome
  11 mm
• Design
  Round, High calotte
• Diameter total
  39.5 mm
• Standards
  EN 60947-5-1, IEC/EN 60947-1
• Sealing type
  Membrane, Lip gaskets, Form seals
• Material of the dome
  Plastic
• Tightening torque of the screw
  0.6 Nm
• Mounting
  Mounting flange ELM
• Material of the front ring
  Aluminium
Mounting flange
Yes
Integral System Diagnostics, general
No
Illuminable
Yes
Fully insulated
Yes
Gross weight
45 g
Colour of the dome
White
Colour of the front ring
Silver
Versions
LED - Indicator light - Front plate mounting
